GJS Series Plane Gyratory Screen
- Widely used for fine screening of powders, granules, and other fine materials in chemical, food, pharmaceutical, and mineral processing industries.
- Designed for efficient screening and precise classification of bulk materials.
- Gyratory screening motion provides stable material flow and high screening accuracy.
- Suitable for fine and medium-sized materials requiring efficient and continuous screening.
Request a Quote
Enter the quantity you need and add to your quote list for pricing inquiries.
Description
Application
Suitable for screening and classification of powders, granules, and bulk materials.
Widely used in mining, aggregates, chemical, food, and other industries requiring efficient material separation.
Feature
Gyratory motion provides efficient screening with stable and controlled material flow.
Large screening area improves processing capacity and screening efficiency.
Multiple screening decks available for simultaneous classification of different particle sizes.
Customized design available to meet specific capacity and application requirements.
Advantage
High screening efficiency with accurate material separation.
Large processing capacity for continuous screening applications.
Stable screening performance with reduced material blockage.
Flexible configurations for different materials and screening requirements.
Options
Customized screen dimensions available.
Various screen media options, including polyurethane, stainless steel, and woven wire mesh.
Single, double, and multiple deck configurations available.
Different feeding and discharge configurations available.
Base-mounted or suspended-mounted available.
Specifications
| Parameter | Value |
| Material | Stainless steel, Carbon steel |
| Mounting Type | Base-mounted,Suspended-mounted |
| Screen Wideth | 1-2 m |
| Screen Length | 2.1-5 m |
| Layer | 1-3 |
| Sieve Angle | 5±3° |
| Rotation Frequency | 180-200 r/min |
| Screen Box Movement | 63-92 mm |
| Power | 3-11 kW |
*Choose the suitable specifications based on your requirements,and contact us for customized solutions
Downloads
| File | Download |
|---|---|
| Screening Equipment Catalog.pdf | Download |
